Bearing Code
|
Dimensions(mm)
|
Load ratings(KN)
|
≈a°
|
Weight(kg)
|
||||||||||
|
d
|
B
|
dk
|
C1 max
|
d2
|
d3 6H
|
h1
|
I1 min
|
I2
|
I7
|
Dynamic
|
Static
|
|||
|
SA5C
|
5
|
6
|
10
|
4.5
|
21
|
M5X0.8
|
36
|
16
|
46.5
|
11.5
|
3.6
|
3.9
|
13
|
0.017
|
|
SA6C
|
6
|
6
|
10
|
4.5
|
21
|
M6X1
|
36
|
16
|
46.5
|
11.5
|
3.6
|
5.5
|
13
|
0.017
|
|
SIA8C
|
8
|
8
|
13
|
6.5
|
24
|
M8X1.25
|
42
|
21
|
54
|
13
|
5.8
|
10
|
15
|
0.029
|
|
SA10C
|
10
|
9
|
16
|
7.5
|
29
|
M10X1.5 M10X1.25
|
48
|
26
|
62.5
|
15.5
|
8.6
|
16
|
12
|
0.05
|
|
SA12C
|
12
|
10
|
18
|
8.5
|
34
|
M12X1.75 M12X1.25
|
54
|
28
|
71
|
18
|
11
|
23
|
10
|
0.066
|
|
SA15C
SA15ET-2RS |
15
|
12
|
22
|
10.5
|
40
|
M14X2
|
63
|
34
|
83
|
21
|
18
25 |
32
|
8
|
0.12
|
|
SA17C
SA17ET-2RS |
17
|
14
|
25
|
11.5
|
46
|
M16X2
|
69
|
36
|
92
|
24
|
22
32 |
44
|
10
|
0.19
|
|
SA20C
SA20ET-2RS |
20
|
16
|
29
|
13.5
|
53
|
M20X1.5
|
78
|
43
|
104.5
|
25.5
|
31
45 |
60
|
9
|
0.31
|
|
SA25C
SA25ET-2RS |
25
|
20
|
35.5
|
18
|
64
|
M24X2
|
94
|
53
|
126
|
31
|
51
85 |
83
|
7
|
0.56
|
|
SA30C
SA30ET-2RS |
30
|
22
|
40.7
|
20
|
73
|
M30X2
|
110
|
65
|
141.5
|
35.5
|
65
110 |
110
|
6
|
0.89
|
|
SA35ET-2RS
|
35
|
25
|
47
|
22
|
82
|
M36X3
|
140
|
82
|
181
|
41
|
140
|
146
|
6
|
1.4
|
|
SA40ET-2RS
|
40
|
28
|
53
|
24
|
92
|
M39X3
|
150
|
86
|
196
|
47
|
175
|
180
|
7
|
1.8
|
|
SA45ET-2RS
|
45
|
32
|
60
|
28
|
102
|
M42X3
|
163
|
92
|
214
|
52
|
225
|
240
|
7
|
2.5
|
|
SA50ET-2RS
|
50
|
35
|
66
|
31
|
112
|
M45X3
|
185
|
104
|
241
|
60
|
275
|
290
|
6
|
3.6
|
|
SA60ET-2RS
|
60
|
44
|
80
|
39
|
135
|
M52X3
|
210
|
115
|
277.5
|
75.5
|
430
|
450
|
6
|
5.7
|
|
SA70ET-2RS
|
70
|
49
|
92
|
43
|
160
|
M56X4
|
235
|
125
|
315
|
95
|
550
|
610
|
6
|
7.9
|
|
SA80ET-2RS
|
80
|
55
|
105
|
48
|
180
|
M64X4
|
270
|
140
|
360
|
105.5
|
705
|
750
|
6
|
12
|
SA…C/SA…ET-2RS
SA…C
*For left-hand thread,suffix”L”is added to bearing number and thread sign,e.g.SAL20C M20X1.5L-6g.
SA..C is equivalent to GAR..UK INA,SL..ET-2RS is equivalent to GAR..UK-2RS.
Sliding contact surfaces:Steel/PTFEcomposite material
